INJECTION MOLDING MACHINE / HORIZONTAL
Keywords：
Chemicals
Classification
Press/Vulcanizer
Hot-line：
+86 411 8285 6376
Details
Mold opening method
FEATURE
♦Low pressure for mold protection.
♦Multi-stages control up-down.
♦Pressure stable, accurate, quiet.
♦Temperature accurately, Exhaust accurately, low noise.
♦Various function, HMI / PLC controlled.
INJECTION SYSTEM
♦Multi-step pressure, speed and injection volume control.
♦Digital injection volume control system design.
♦Injection head has a spiral-circuit temperature control.
MATERIAL FEEDING SYSTEM
♦A material anti-reversing device is equipped.
CONTROL UNIT
♦Fully functional flow control display.
♦User-friendly software programming.
♦Multi sets of molding daya memories.
♦Whole-unit breakdown detecting function.
SPECIFICATION
|
MODEL |
PLATFORM (mm) |
MOTOR (HP) |
OUTPUT (Tons) |
CYLINDER DIAMETER (mm) |
STROKE (mm) |
INJECTION VOLUME (C.C) |
SCREW DIAMETER (MM) |
|
INJ-100 |
460x460 |
10 |
100 |
Φ250 |
450 |
1000 |
Φ44 |
|
INJ-200 |
550x550 |
15 |
200 |
Φ350 |
450 |
1600~2000 |
Φ44 |
|
INJ-300 |
600x600 |
20 |
300 |
Φ450 |
450 |
2500~3000 |
Φ44 |
|
INJ-400 |
700x700 |
20 |
400 |
Φ500 |
450 |
3000~6000 |
Φ50 |
|
INJ-500 |
700x750 |
30 |
500 |
Φ560 |
450 |
4000~12000 |
Φ70 |
|
MODEL |
MATERIAL CYLINDER DIAMETER (mm) |
INJECTION CYLINDER DIAMETER (mm) |
UNIT PRESSURE (kgf/cm²) |
MACHINE (M) |
WEIGHT (KG) |
||
|
INJ-100 |
Φ65 |
Φ200 |
|
210 |
2.2x1.6x2.3 |
4500 |
|
|
INJ-200 |
Φ75 |
Φ225 |
|
210 |
2.5x1.8x2.5 |
6500 |
|
|
INJ-300 |
Φ90 |
Φ275 |
|
210 |
4.1x2.6x2.8 |
9000 |
|
|
INJ-400 |
Φ120 |
Φ300 |
|
210 |
4.1x2.4x2.8 |
11000 |
|
|
INJ-500 |
Φ130 |
Φ330 |
|
210 |
5.1x2.5x3.4 |
13000 |
